Angle Sensor1/2.9\" GC2063CMOS
Min. Illumination
Color: 0.05lux (F1.6), 0 lux withIR light
Shutter Speed
1/10s to 1/10,000 s
Slow Shutter
Yes
Day & Night
IR CUT Filter
Digital Noise Reduction
3D DNR2D 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Lens
Focal Length
Fixed focal lens,dual lens,4 & FOV
FOV
4mm, horizontal FOV: 170°, vertical FOV: 40°
Lens Light & IR Range
Up to 30 m
Smart Supplement Light
Yes
Compression Standard
Video Compression
Main stream: H.265+/H.265/H.264
Sub-stream: H.265+/H.265/H.264
H.264 Type
High Profile/Main Profile/Base Profile
H.265 Type
High Profile/Main Profile/Base Profile
H.265+
High Profile/Main Profile/Base Profile
Smart Feature-set
Smart Event
Human detection
Basic Event
Motion detection
Linkage Method
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email
Trigger notification: HTTP, Email
Max. Resolution
3840× 1080
Main Stream
50Hz: 20fps 3840× 1080
60Hz: 20 fps 3840× 20fps 1280 x 360
60Hz: 20fps1280 x 360
Image Enhancement
WDR/HDR/3D DNR/2D DNR/HLC/BLC
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser
SVC
H.264 and H.265 encoding support
Day/Night Storage
Support local storage and NAS (NFS, SMB/CIFS)
Protocols
HTTP, RTSP, DHCP, FTP, Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Built-in Microphone
Yes
Built-in Speaker
Power: 3W.MAX. Sound pressure lever:10cm: 100dB.
Reset Key
Yes
On-Board Storage
Built-in memory card slot, support microSD card,up to 512GB support microSD card,up to 512GB support microSD card,up to 512GBsupport microSD card,up to 512GB
General
Operating Conditions
-30 °C to +85°C, humidity 95% or less (non-condensing)
Web Client Language
14languages: English,Russian,German,Italian,Turkish, Korean,Japanese,Traditional Chinese, Consumption and Current
DC12V, 1A, max. 10WΦ 5.5X2.1mm coaxial plug power
PoE (802.3af, 36 V to 57 V), 0.35A to 0.22A, max. 12.5W
Protection Level
IP67-Each Camera has been tested waterproof
Material
Front 236.1× 110x 74mm (9.29\" × 4.33 x 2.91\")
Package: 325× 125× 120mm (12.8\" ×4.92\" ×4.7\" )
Weight
Apporx.650g(1.43 lb)
With Package Weight
Apporx.800g(1.76 lb)
