Product Name :C-CS Mount Adapter Ring
Material :Premium Matte Aluminum AlloyCore Functions
1. Convert between CS-mount camera and C-mount lens to unify interface and adjust back focal length.
2. Increase flange focal distance when both camera and lens adopt C-mount standard.Available Sizes
1. Standard thickness options: 0.5mm/1mm/2mm versions are plain spacer washers without internal threads, identical outer diameter, differing only in thickness.Product Description
1. C vs CS Mount Definition
All industrial camera lenses feature threaded mounting; two mainstream industrial specs: C-mount & CS-mount, sharing identical thread dimension but different flange focal distance.
- C-mount flange focal length: 17.562mm
- CS-mount flange focal length: 12.5mm
Adapter ring is required to install C-lens onto CS camera or vice versa.2. Product Advantage
Fabricated from high-grade matte aluminum with fine machining; anti-slip thread, no paint peeling. Widely used for machine vision & CCTV surveillance, adjusting back focus to acquire sharp optimal imaging when out-of-focus occurs.3. Application Scene
Fit CS-mount camera equipped with C-type lens via this C-CS adapter spacer. Both mounts adopt 1-inch standard lens thread, distinguished solely by the distance from lens mounting surface to image sensor.
