LS Oil Pan Aluminum Low-profile Rear-sump 6.0-Quart for Chevy Small Block V8
Specifications:
Sump Style : Wet
Sump Location : Front
Sump Depth : 5.625"
Maximum Stroke : 4.25"
Sump Oil Capacity : 6.0 Quarts
Total Oil Capacity : 6.2 Quarts with Stock Filter
Baffled : Yes
Windage Tray : Not Included
Oil Pick-Up : Included
Gasket : Pan Gasket
Sump Baffle
Oil Pickup Tube
Drain Plug
Oil Filter Stud
Oil Passage Cover
Mounting Chevrolet Small Block V8 Gen. III/IV (LS-Based) 4.8 L / 293
for Chevrolet Small Block V8 Gen. III/IV (LS-Based) 5.3 L / 325
for Chevrolet Small Block V8 Gen. III/IV (LS-Based) 5.7 L / 346 commonly referred to as 350
for Chevrolet Small Block V8 Gen. III/IV (LS-Based) 6.0 L / 364
for Chevrolet Small Block V8 Gen. III/IV (LS-Based) 6.2 L / 376
⚠️ LS SWAP FITMENT NOTE (PLEASE READ BEFORE BUYING)
Engine Fitment: Fits GM Gen III/IV LS V8 engines (4.8L, 5.3L, 5.7L, 6.0L, 6.2L). Does NOT fit dry-sump (LS7/LS9).
Chassis Clearance: This is a Universal Front-Sump oil pan. Buyers must measure and verify front-sump chassis clearance before purchasing.
Oil Filter & Dipstick: Requires AC Delco PF48/PF48E filter (Not included). Stock dipstick will not work; requires a front-sump specific dipstick.
Disclaimer: Fitment is guaranteed to the engine block only. Custom fabrication or chassis modification may be required for installation.
