STARTBOY1010 TESTED WORKING OEM PART
This listing is for one genuine OEM LiftMaster / Chamberlain receiver logic board.
The board is used, inspected, tested, and confirmed working before shipment.
THIS LISTING IS FOR THE CIRCUIT BOARD ONLY.
No complete end panel, garage door opener, motor assembly, LED light assembly, or other components are included unless specifically shown in the listing pictures.
ITEM CONDITION AND TESTING
- Used genuine OEM part
- Tested and working
- Connectors and mounting areas inspected
- Normal cosmetic signs of previous use may be present
- Listing pictures are part of the item description
IMPORTANT PART VERIFICATION
Before purchasing, carefully compare:
- Original part number
- Board markings
- Learn button color
- AC or DC platform
- Lock terminal configuration
- Connectors
- Component layout
- Mounting points
- Complete garage door opener model
- Listing pictures
Identification associated with this listing includes:
- LiftMaster service kit number 041D9276
- Board marking 50DCBL5LK
- DC receiver logic board platform
- Wi-Fi / myQ capable
- Lock-capable platform
- Security+ 2.0
- Yellow Learn Button
IMPORTANT:
041D9276 is the LiftMaster service-kit number for an End Panel / Receiver Logic Board assembly used in specific applications.
This listing is for the circuit board only unless the listing pictures and description specifically show additional parts.
The service-kit number alone does not guarantee compatibility.
The original board number, connectors, lock terminals, component layout, opener model, and Yellow Learn Button must match.
Please do not purchase based only on appearance or Learn button color.
If uncertain, send clear pictures of:
- Original logic board
- All board labels
- Connectors
- Lock terminals
- Garage door opener model label
through messages before purchasing.
VERIFIED PLATFORM INFORMATION
This board family is associated with:
- DC motor garage door opener platforms
- Wi-Fi / myQ connectivity
- Security+ 2.0
- Lock-capable systems
- Yellow Learn Button
- Belt-drive, chain-drive, or wall-mount applications depending on model
Directly documented applications in this logic-board family include:
- LiftMaster WLED
- LiftMaster 8550WL
- LiftMaster 8587WL
- LiftMaster 8360WL
- LiftMaster 8500W
WLED APPLICATION
LiftMaster identifies 041D9276 specifically as an End Panel / Receiver Logic Board replacement kit for the WLED garage door opener.
The WLED is a:
- DC platform
- Battery-backup platform
- Belt-drive platform
- LED lighting platform
- Wi-Fi / myQ platform
- Lock-capable platform
8550WL APPLICATION
LiftMaster service documentation identifies:
- 8550WL
- Receiver Logic Board 050DCTWFLK
Do not confuse the 8550WL lock-capable model with the earlier non-lock 8550W configuration.
8587WL AND 8360WL APPLICATIONS
LiftMaster service documentation identifies the lock-capable versions of the 8587W and 8360W families as using the 050DCTWFLK DC Wi-Fi Lock Receiver Logic Board.
Lock-capable units are identified by:
- Model designation containing the letter L
- Two automatic garage door lock terminals
- Appropriate lock-capable logic board
Lock-capable and non-lock-capable boards are not interchangeable.
8500W APPLICATION
LiftMaster documentation identifies the 8500W wall-mount opener as using 050DCTWFLK as its replacement DC Wi-Fi logic board.
The 8500W also uses automatic garage door lock capability.
IMPORTANT:
Because 041D9276 itself is specifically documented for WLED, customers purchasing this board for another model must verify the original board number, connectors, terminal configuration, and physical layout before ordering.
OEM PART NUMBER AND CROSS-REFERENCE INFORMATION
Related numbers within this platform include:
- 041D9276
- 50DCBL5LK
- 050DCTWFLK
Later OEM replacement families include:
- 050DCTBLK
- 050DCTBLKMC
- 050DCTBFLKMC
050DCTWFLK is an older DC Wi-Fi Lock-Capable receiver logic board.
Later Bluetooth-enabled replacement boards are documented by LiftMaster for select applications.
The fact that a newer board replaces an older board does not automatically guarantee that this older 50DCBL5LK / 050DCTWFLK board can be installed in every opener originally designed for the newer Bluetooth-enabled board.
Reverse compatibility is not guaranteed.
NOT COMPATIBLE WITH
Do not purchase this board for:
- Non-lock-capable models
- 050DCTWF non-lock boards
- AC motor logic boards
- 050ACT series boards
- Purple Learn Button systems
- Red or Orange Learn Button systems
- Green Learn Button systems
- Boards with different connectors
- Boards with different lock terminals
- Boards with different component layouts
- Models requiring another logic board number
- Newer platforms unless the original board and application are specifically verified
DC and AC logic boards are not interchangeable.
Lock-capable and non-lock-capable logic boards are not interchangeable.
A Yellow Learn Button alone does not confirm compatibility.
WHAT IS INCLUDED
- One tested OEM receiver logic board
- Board only
- Only the components physically attached to the board and shown in the listing pictures
Unless specifically pictured and stated, the following are not included:
- Complete 041D9276 end panel kit
- Plastic housing
- End panel
- LED light connector harness
- LED light assembly
- Motor
- Travel module
- Battery
- Transformer
- Automatic garage door lock
- Remote controls
- Wireless keypad
- Wall control
- Safety sensors
- Wiring
- Screws
- Complete garage door opener
INSTALLATION AND PROGRAMMING
Disconnect electrical power and battery power before removing or installing the logic board.
Professional installation is recommended.
After installation, programming or setup may be required for:
- Remote controls
- Wireless keypad
- Wi-Fi / myQ
- Travel limits
- Door-position settings
- Force settings
- Automatic garage door lock
- Wall control accessories
Programming requirements vary by opener model.
IMPORTANT DIAGNOSTIC INFORMATION
Replacing the logic board will not repair unrelated problems involving:
- DC motor
- Motor or drive assembly
- Travel module
- Position sensor
- Battery
- Battery charging system
- Automatic garage door lock
- LED lighting system
- Wall control
- Remote controls
- Wireless keypad
- Safety reversing sensors
- Sensor wiring
- Door balance
- Springs
- Tracks
- Rollers
- Mechanical obstruction
- Wi-Fi router or Internet connection
- Other garage door opener components
The buyer is responsible for correctly diagnosing the original problem before purchasing.
Replacing the logic board is not guaranteed to correct every garage door opener problem.
IMPORTANT PURCHASING INFORMATION
Please verify compatibility before purchasing.
STARTBOY1010 is not responsible for:
- Incorrect diagnosis
- Incorrect part selection
- Incompatible opener model
- AC / DC platform confusion
- Lock / Non-Lock confusion
- Different board generation
- Installation errors
- Programming errors
- Damage caused during installation
- Problems located outside the logic board
Installation, removal, labor charges, diagnostic expenses, service calls, and technician expenses are not included.
Returns and refunds are handled according to the listing terms and applicable policies.
A board that has been physically damaged, altered, incorrectly installed, or subjected to unauthorized repair may not qualify for return under the applicable return conditions.
PROFESSIONAL PACKAGING
The board will be carefully packaged to help protect the circuit board, connectors, Learn button, and electronic components during shipment.
STARTBOY1010 BUSINESS INFORMATION
Electronic Parts and Professional Repair Service
19 PLUS YEARS OF SELLING EXPERIENCE
SPANISH ASSISTANCE AVAILABLE
FINAL REMINDER
THIS LISTING IS FOR ONE TESTED OEM CIRCUIT BOARD ONLY.
The complete 041D9276 end panel assembly is not included unless specifically shown in the listing pictures.
Verify the original board number, DC platform, lock-terminal configuration, connectors, component layout, and Yellow Learn Button before purchasing.
