Same specs as the following :
Freedom Hydraulics S254
Enerpac RC254
Simplex R254
SPX C254C
Eagle Pro ES254
BVA Hydraulics H2504
Dimensions
Thread Size 1/2"-13
Center Hole Dia. 2 1/4 in
Outside Dia. 3.38 in
Stroke Length 4 in
Plunger Thread Size 1-1/2"-16
Collar Thread Size 3-5/16"-12
Bolt Circle Dia. 2.31"
Extended Height 12.5 in
Plunger Dia. 2.25 in
Retracted Height 8.5 in
Base Bolt Circle Dia. 2.31 in
Nominal Stroke Length 4 in
Details
Body Material Steel
Weight Capacity 25 tons
Effective Area 5.14 sq. in.
Item Hydraulic Ram
Max. Pressure 10,000 psi
Handle No
Single Acting/Double Acting Single Acting
Oil Capacity 20.63 cu. in.
Cylinder Type General Purpose
Includes Coupler, Dust Cap
Max. Push Capacity 25 ton
Series RS
Effective Push Area 5.16 sq in
Nominal Capacity 25 ton
Oil Capacity Push 20.63 cu in
Finish Paint
Type General Purpose
Get the matching seal kit for this 25 Ton cylinder: Seal Kit for RokSolid 25 Ton Hydraulic Cylinders (Item 326834457990) — designed specifically for repairs and long-term performance.
