Our Restoration Procedures:
1. Check Out The Stereo, If There Is Anything Wrong, We Will Fix It.
2. Clean & Lubricate All Of The Switches & Controls.
3. Electrolytic Capacitor Check, If There Is Any Weak One, We Will Change It.
4. FM IF & MPX Circuit Alignment By Using A Sweep Signal Generator & Victor Scope.
5. Change Burned Lamps.
6. Check Out & Adjust Power Amplifier\'s Center Voltage &StandbyCurrent.
7. Audio Frequency Response & Distortion Test.
8. Clean All Of The Knobs By Ultrasonic Cleaner.
9. Functional Check.
0.All Sales We Give A 90-Day Labor & Parts Warranty, If There Is Any Problem, You Send It Back We Will Repair It For You Free Of Charge, You Pay The Send-In Postage, We Pay The Send-Back Postage.Specifications
Tuning range: FM, MW
Power output: 26 watts per channel into 8? (stereo)
Frequency response: 20Hz to 50kHz
Total harmonic distortion: 0.1%
Damping factor: 40
Input sensitivity: 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 77dB (MM), 100dB (DIN), 100dB (line)
Output: 150mV (line), 30mV (DIN)
Speaker load impedance: 4? to 16?
Dimensions: 468 x 140 x 348mm
