ASCO RedHat 8215B50 – 2-Way Solenoid Valve
The ASCO RedHat 8215B50 is a direct-acting, normally closed two-way solenoid valve with a 1" NPT aluminum body, built for air and fuel-gas service in low-pressure applications. When the coil is de-energized the valve stays closed; energizing the coil opens the large 1-5/8" orifice for high-flow on/off control.
Its lightweight aluminum construction and high flow factor make it a common choice for combustion air, gas-train, and burner-control duty where a large-port shutoff valve is required.
Confirmed Specifications
- Series: RedHat 8215
- Catalog Number: 8215B50
- Configuration: 2-way, normally closed
- Pipe Size: 1" NPT
- Body Material: Aluminum
- Orifice: 1-5/8"
- Flow Factor: Cv 21
- Maximum Operating Pressure: 50 psi
- Maximum Fluid Temperature: 125°F
- Service Media: Air & fuel gas
Typical Applications
- Combustion air and gas-train shutoff
- Burner and furnace control systems
- Low-pressure air and inert-gas on/off control
- Industrial process and OEM equipment
