DDP Rare Technics SH-305MC MC Step Up Transformer Amorphous Core EXC+ JAPAN JP For Sale

THIS ITEM IS SHIPPED DDP (DELIVERY DUTY Product Title / Catch Phrase
Technics SH-305MC Audiophile MC Step-Up Transformer - Dual Amorphous Toroidal Cores2️⃣ Description / Overview
The Technics SH-305MC represents a monumental engineering achievement from the golden era of Japanese analog audio, acclaimed and chosen by vinyl connoisseurs and audiophiles around the world. Developed by Matsushita/Technics to unlock the ultimate potential of high-end MC cartridges, it incorporates ultra-thin amorphous spiral-wound ribbon cores in a dual-mono toroidal configuration. Housed within a massive 4.5kg cast-iron and aluminum shielded enclosure, it suppresses external flux while reproducing breathtaking transparency and dynamic range. This unit has been demagnetized and detailed, performing in solid working order.3️⃣ Features
* Dual-mono toroidal transformers utilizing advanced ultra-thin amorphous spiral-wound cores
* Heavy-duty 4-fold magnetic shielding combining dual permalloy cases and copper-plated cast iron
* 4-position impedance selector switch (Pass, 3 Ohms, 15 Ohms, 30 Ohms) for universal MC matching
* Ultra-heavyweight 4.5kg vibration-damping chassis minimizing unwanted mechanical resonance
* Ultra-wide frequency response from 3 Hz to 300 kHz with virtually unmeasurable distortion4️⃣ Specifications
* Type: Step-Up Transformer for MC (Moving Coil) Cartridges
* Transformer Architecture: Dual Amorphous Toroidal Cores (Left / Right Independent)
* Input Impedance: Pass (MM Through), Low (3 Ohms), Middle (15 Ohms), High (30 Ohms)
* Frequency Response: 3 Hz - 300 kHz (20 Hz - 100 kHz +/-0.2 dB)
* Total Harmonic Distortion: 0.001% or less (1 kHz)
* Channel Separation: 90 dB or greater (1 kHz)
* Shielding: 4-fold shielding (Double Permalloy + Copper-plated Cast Iron Case)
* Recommended Load Impedance: 47 kOhms
* Dimensions: 60 mm (W) x 90 mm (H) x 210 mm (D) / 2.4\" x 3.5\" x 8.3\"
* Weight: Approx. 4.5 kg (9.9 lbs)
* Country of Origin: Japan5️⃣ Condition
Overall Rating: Excellent+
* Fully tested and confirmed operational; reproduces balanced, transparent audio across both channels with smooth impedance switching.
* Cosmetically well-preserved with minor cosmetic surface scuffs and hairline marks consistent with vintage use; no deep gouges, structural dents, or severe corrosion.
* Clean rear RCA terminals and solid chassis construction.
* Please also check the photos for detailed cosmetic condition.Maintenance Details:
* Comprehensive core de-magnetization process performed to eliminate residual magnetic hysteresis
* Exterior chassis and audio terminal contacts detailed and cleaned6️⃣ Included Items
* Technics SH-305MC Step-Up Transformer Unit
(Please note that only the items shown in the photos are included. Factory box is not included.)7️⃣ Keywords (for search)
