For ESP32 S3 DIV V2.0 Modular Development Board with for antenna Interface
DESCRIPTION
Features:
- for ESP32-DIV V2.0 is an upgraded open- for source handheld wireless toolkit designed for multi-band experimentation. Based on the powerful for ESP32-S3 core, this version features a modular "sandwich" design, integrating , and Sub-GHz capabilities into a single portable device.
Key upgrades in V2.0:
- Processor Core: Upgraded to for ESP32-S3 for better USB support and expandability.
Modular Design: Utilizes a new spring-loaded connector for a thinner, cleaner stack, eliminating bulky connectors.
- Visual : Adds four for WS2812B RGB LEDs and an integrated buzzer for real-time state alerts.
- Power Management: Integrated IP5306 IC for stable for battery charging and power delivery.
Key Functions and Tools:
- Tools: Packet monitoring (real-time waterfall graph), broadcast unwanted traffic generator, de-identification detector, and scanner.
for Spectrum: 128-channel scanner for detection and proprietary protocols.
Infrared (IR): Visualizes and reuses infrared remote Name: for ESP32-DIV V2.0 Development Board
Material: ABS
size: As shown
Color: Black
- Main Chip: for ESP32-S3 (with 16MB for Flash).
- Display: for 2.8-inch for ILI9341 TFT touchscreen for intuitive user interface .
- RF Modules:
3 modules for advanced analysis.
1 Sub-GHz transceiver for Sub-GHz protocol testing.
- Storage: Built-in TF/ for SD card slot for recording packet captures (PCAP) and storing transmission data.
- Connectivity: External for SMA interface for maximum transmission distance and flexibility.
Package Contents:
1 x for ESP32-DIV V2.0 Motherboard
1 x Shielding Cover (NRF24 + Integrated)
1 x Kit (depending on model)
1 x Buzzer
1 x for Type-C Data Cable
1 x Plastic touch pen Pen
Notes:
- 433 pin conflicts with UART and cannot be used simultaneously.
- band conflicts with infrared.
- for SD card program has issues and may erase data.
- The charging program shares a pin with the buzzer, causing the buzzer to sound. The buzzer is not soldered but will be shipped with the package.
- for ESP32-DIV V2.0 Handheld Wireless Analysis and Test Kit
- The comprehensive for multi-band wireless tool for IoT developers and security researchers
- This product does not include a for battery. You will need to connect to a power for source to use onlyship to confirmed Order addresses.Please comfirm that your Order address is in line with your shipping address.
