Ibanez Jem HSH wiring upgradeNo soldering requiredCompletely wired (not a kit) Madeto fit and ready to installCharlies Gear USAFeatures:Solderless installation & solderless future pickup swaps Master volume / master tone / 5-way blade switchFor humbucker bridge/Single coil mid/Humbucker neck models (HSH)Push/pull tone coil splits Bridge & Neck - Pull up knob for single coilResistor added for single coil / humbucker combination - so each pickup \"sees\" the correct potentiometer value for the pickup typeSWITCHING:This has a 5-way switch with the following switching:1- B2- B+M3- M4- M+N5- NDedicated control cavity ground to reduce noiseBourns pro-audio 17mm potentiometers - High quality in a smaller packageMulti-contact Barrel jack with 100% more signal transfer areaShielded cable to jack to protect your signal from RF interference noiseQuick-connector on jack cable - just plug it in (1/4\" clearance required at feed-thru hole to jack)2 grounding options included for strings & hardwareOrange drop tone capacitorUSA speccomponentsScroll below for complete component specsUpgrading an import?These upgraded potentiometers & jack require 3/8\" diameter mounting holes. Hand reamers are the safest, easiest & best way to enlarge holes. You can find very affordable hand reamers in Charlies Gear store at the \"Helpful tools\" category if you need one. Installation:This system is designed to make upgrading your electronics with premium components easy, quick and frustration free.1- Install stripped wires into the solderless terminal ports and secure with the included screwdriver2- Mount your new harness in the control cavity3- Plug the solderless terminal into the harness.BING - BANG - BOOM - DONE!Plus, no burned fingers!***Makes future pickup upgrades a snap***Specifications:
Wiring harness for Ibanez HSH JEM
Master volume / master tone / 5-way switch
Bourns500kpro-audio 17mm potentiometers
Push/pull tone wired to coil split Neck & Bridge
Brassbushings provide longer life and smooth operation
Split shaft 18 spline (for knobs)
Orange drop.022uF tone capacitor
Resistor added for single coil circuit
Oak Grigsby 5-way blade switch - Smooth roller bearing action
Pure tone multi-contact barrel jack
Shielded jack cable with plug-inQuick connector
24-gauge wires & 22-gauge cables
Premium grade solderless terminals for your wire connections
2mm screwdriver for terminals
Installation hardware
Installation wiring guide
