EXTREMELY RARE WITH ORIGINAL SERIAL # MATCHING BOX, FOAM PACKING CORNERS, OEM RCA CABLE & OEM AC PLUG ADAPTER!!!!
UNIT IS IN EXCELLENT COSMETIC CONDITION AND POWERS ON WITH THE DISPLAY PANEL LIGHTS WORKING FINE!!! THE MOTORIZED TRAY WILL NOT OPEN AND THE REC SIGNAL SELECTOR BUTTON BARELY WORKS SO THAT BUTTON NEEDS SERVICED!!!!
THATS ALL I TESTED AS I DONT KNOW TOO MUCH ABOUT THIS UNIT SO SELLING PARTS OR REPAIR ONLY!!!!
The JVC SEA-M9B is a high-end, computer-controlled stereo graphic equalizer featuring touch controls and a motorized slide-out panel.
Key Specifications
• Frequency Response: 10 Hz to 100 kHz
• Total Harmonic Distortion (THD): 0.003% (20 Hz - 20 kHz, rated output)
• Signal-to-Noise Ratio (SNR): 118 dB
• Rated Output: 2 V RMS
• Maximum Output: 5 V RMS
• Control Range: ±12 dB / ±6 dB
• Frequency Bands (12 per channel): 16 Hz, 31.5 Hz, 63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4 kHz, 8 kHz, 16 kHz, and 32 kHz
• Input Impedance: 47 kohms
• Output Impedance: 100 ohms
• Dimensions (W x H x D): 435 x 149 x 377 mm (approx. 17.1 x 5.9 x 14.8 inches)
• Weight: 10 kg (22 lbs) net
• Finish: Black
• Release Year: 1984
