StewartHeadwind Aircraft Plans Don Stewart Homebuilt Airplane,PDF,JPG Files
Description
StewartHeadwind Homebuilt Aircraft Plans — Don Stewart
Digitalaircraft drawing collection for the classic Stewart Headwind single-seathomebuilt aircraft.
The Headwindis a high-wing, tube-and-fabric aircraft designed by Don Stewart, with theoriginal design dating to 1962. �
Filesincluded:
PDF drawings
Fuselage andstructural details
Engineinstallation information
Landing geardetails
Tail andcontrol-surface information
Wingspan: 28ft 3 in
Length: 17 ft
Wing area:110.95 sq ft
Gross weight:approximately 750 lb
VW conversionengine: approximately 63 hp
Cruise:approximately 80–85 mph
Maximumspeed: approximately 105–110 mph
DIGITALPRODUCT — PDF + JPG
