Offered is a:
Tested Huber Ministat 230 Refrigerated/Heating Chiller Circulator -40 to +200deg C
Tested to -30C and +60C,
Please see Video and Pictures, Great Working condition!!
You are welcome to pickup locally - free of charge -Natick MA 01760
Shipping will be flat rate $450 in the US
(48 States - Not including Alaska & Hawaii)
Delivery In Massachusetts within Interstate 495 will be $200.
We ship out of the US, Please send me an Email and I will quote shipping.
Huber Ministats are the smallest cooling circulator in the world. Their small dimensions allow Ministats to be placed in the smallest of spaces, for example in a laboratory fume cupboard or inside technical plant. Despite their minimal size the systems are extensively fitted out and offer sufficient performance for temperature control of photometers, refractometers, viscometers, distillation apparatus, reaction vessels and mini-plants. The main applications are using external applications however the bath opening allows objects to be thermoregulated directly in a thermostat bath. A powerful pressure/suction pump with an infinitely controlled rotational speed ensures optimal circulation. The maximum pressure can also be regulated by an optional pressure sensor, meaning that sensitive glassreactors and apparatus can reliably be protected from breakage. Additionally, Ministats offer the Pilot ONE controller as standard with a colour TFT display and comfortable operator guidance. Analogue connections according to NAMUR are available via the optional Com.G@te module allowing Ministats to integrate into plant and process control systems.
General information & temperature controller
Temperature range
-40...200°C
Temperature stability
±0.02°C
Controller
Pilot ONE (E-grade\"Basic\")
Safety class
III / FL
Protection class
IP20
Dimensions(W x D x H)
255 x 450 x 476mm|10.04 x 17.72 x 18.74inches
Weight
37kg|81.59pounds
Heating / cooling capacity
Heating capacity
1,5kW
Cooling capacity
100
20
0
-10
-20
-40
°C
0,42
0,42
0,38
0,33
0,25
0,05
kW
Cooling machine
air-cooled
Refrigerant(ASHRAE, GHS)
R290 (A3, H220) (0,099 kg)
Circulation pump
Pressure pump max.
Suction pump max.
Pump connection
M16x1 AG male
Permissibleviscosity
50mm²/s
Pump speed adjustable
Yes
Connections
Pt100 connection
Pt100
Digital interface
RS232, Ethernet, USB Device, USB Host
Operating data
Permissible ambient temp.
5...40°C
Bath openingW x D / BD
170 x 85 / 135mm|6.69 x 3.35 / 5.31inches
Bath volume
3.2Liters|0.85gal
Filling volume min.
2.8Liters|0.74gal
Power supply
110-120V 1~ 60Hz
Current max.
14A
Fusing
16 A
