SBC V Pulley + Bracket Kit & Power SteeringPumpLong Water Pump Alternator High Mount
Application:
New Small Block Chevy 2 Groove Pulley Kit W/ Key Way Power Steering Pulley
This is a Bright Machining FINISH Dual V-groove water pump pulley kit.
This pulley work on all Small Block Chevy Motors From 1959-1995 283 327 350 400 engines with a "LONG" water pump and “KEY WAY” style power steering pumps.
Power Steering Pump :
For Small & Big Block Chevy 283 - 305 - 307 - 327 - 350 - 400 396 - 402 - 427 - 454
Chrome Saginaw power steering pump with reservoir & dipstick
Key way style shaft
5/8"-18 Inverted flare pressure hose inlet (adapter required if using metric hose)
Compatible with Single or Double Groove Pulleys (Will NOT Work on Press-on Pulleys)
Pulley Nut & Keyway Tab Included
3/8" Hose Barb Return Line
5/8" Shaft with Keyway
Alternator :
Chrome 1 or 3 Wire GM 130 Amp Alternator
High Mount Alernator Bracket:
Bright Machining
It must have lower outside bolt hole in head
Includes all hardware & stainless steel tension rod
Small Block Chevy High Mount Alternator Bracket passenger side
Made from 11/16" Aluminum 6061-T6
Power Steering Pump Bracket：
Bright machining
Made from 9/16" thick aluminum 6061-T6
Low mount Chevy small block Power Steering bracket for V-belt applications.
Mounts Saginaw P Series Power Steering pump w/Keyway low on driver side.
Small Block Chevy Long Water Pump :
Chrome Long water pump for chevy 283, 327,350 small block engines
High volume aluminum water pump.
Mechanical water pump
Block to hub measurement is 6 15/16". Large 3/4" bearing with 5/8" shaft.
Bigger pump impeller & Larger cavity size
Standard rotation,Includes gaskets.
High quality roller bearings.
Package:
Chrome Saginaw StyleKey WayPower Steering Pump
ChromeSBC Long Water Pump
Chrome 130 amp 1 or 3 Wire GM alternator
DoubleGroove Long Water PumpPulley (6.60" Diameter ，w/ correct mounting bolts)
TripleGrooveLong Water PumpCrank Pulley(6.60" Diameter ，w/ correct mounting bolts)
Single Groove Aluminum Alternator Pulley With Nut Cover
Aluminum Alternator Fan Blade
DoubleGroove "Key Way" Style Power Steering Pump Pulley
Billet AluminumLow Mount Driver SidePower Steering Pump Bracket
Billet AluminumHigh Mount Passenger SideAlternator bracket
P Professional Installation is Highly Recommended (No Instruction and Wiring Diagram Included)
