Same specs as the following :
Freedom Hydraulics S252
Enerpac RC252
Simplex R252
SPX C252C
Eagle Pro ES252
BVA Hydraulics wiper seal keeps out contamination and debris
Upper and lower bearing for minimal wear of cylinder rod and maximizing lifetime of cylinder
Industrial-grade return spring increases retraction speed for improved productivity
Industrial-grade steel construction withstands even the most demanding of applications
Chrome plated piston rod eliminates corrosion and rust
3/8" NPTF female coupler and dust cap
Hardened grooved saddle provides safe load retention
Precision roller burnished cylinder wall
Polyurethane U-Cup provides superior sealing performance that will not leak in the most demanding of industrial Thread Size 3-5/16"-12
Center Hole Dia. 2 1/4 in
Retracted Height 6.5 in
Outside Dia. 3.38 in
Plunger Dia. 2.25 in
Stroke Length 2 in
Bolt Circle Dia. 2.31"
Extended Height 8.5 in
Thread Size 1/2"-13
Plunger Thread Size 1-1/2"-16
Base Bolt Circle Dia. 2.31 in
Nominal Stroke Length 2 in
Details
Body Material Steel
Weight Capacity 25 tons
Cylinder Type General Purpose
Includes Coupler, Dust Cap
Effective Area 5.14 sq. in.
Single Acting
Max. Pressure 10,000 psi
Oil Capacity 10.31 cu. in.
Item Hydraulic Ram
Handle No
Series RS
Oil Capacity Push 10.31 cu in
Nominal Capacity 25 ton
Effective Push Area 5.16 sq in
Max. Push Capacity 25 ton
Finish Baked enameled finish
Type General Purpose
Get the matching seal kit for this 25 Ton cylinder: Seal Kit for RokSolid 25 Ton Hydraulic Cylinders (Item 326834457990) — designed specifically for repairs and long-term performance.
